Challenge 1
Make a gait you can hear: a burst of steps, a pause, repeating. Someone with their eyes shut should be able to say how many bursts there were and how many steps were in each.
What you are building 3 min
The Spider: eight legs driven from a single Large Motor, walking in the alternating pattern that every eight-legged walker uses.
A spider does not walk at a steady pace. It runs a few quick steps, stops dead, waits, then runs again — and that stop-start pattern is far more of what makes something look like a spider than the number of legs is.
That is a pattern made of patterns. Several steps make a dash; several dashes make a journey. And the way you write that is one loop inside another.
In the real world 5 min
Where you have seen it
Jumping spiders are the ones that look back at you. They are small, common across Southeast Asia, and they move in short bursts — a quick run, then absolute stillness, then another run.
Why it is built that way
A spider always keeps some legs on the ground while others swing forward, which is why it never falls over even standing still — with eight legs there is always a stable tripod down. Your model does the same thing mechanically: one motor, a linkage, and legs that take turns.
The stopping matters too. A jumping spider sees badly while it is moving, so it stops in order to look. The bursts are not hesitation — they are how it alternates between travelling and seeing, because it cannot do both at once.
What would go wrong without it
A spider that walked at one constant speed would be easy to spot and easy to follow, and it would never get a clear look at anything. The rhythm is camouflage and it is perception, both at once.
Movement that stops is not movement interrupted. Often the stopping is the point.
The main concept — a pattern of patterns 6 min
There is no new block today. There is a new shape: a repeat block sitting inside another repeat block.
repeat (4)
repeat (3)
[A v] run for (360) [degrees v] at (40) % speed :: motors
end
wait (1) seconds
endRead it from the inside out, because that is the order it happens:
- The inner loop takes three steps, one after another, with nothing between them. That is one dash.
- The wait comes after the inner loop has finished completely. It is inside the outer loop but outside the inner one, and that position is the entire design.
- The outer loop does that whole thing — dash, then pause — four times over.
| Where a block sits | How often it runs |
|---|---|
| Inside the inner loop | 12 times — 3 × 4. The counts multiply. |
| Inside the outer loop, outside the inner | 4 times — once per dash. |
| Outside both | Once. |
The counts multiply, and that catches everybody. A student who wants twelve steps and writes repeat (12) in both loops gets a hundred and forty-four. Decide what one pass of each loop means before you pick either number.
Which loop does a block belong in?
Ask what it belongs to. The stepping belongs to the dash, so it goes inside. The pause belongs between dashes, so it goes in the outer loop after the inner one. A beep announcing a new dash would go at the top of the outer loop, before the inner one starts.
Move a block from one loop to the other and you have not made a small adjustment — you have changed how many times it happens, and usually by a lot.
Repeating
Machines repeat. A wiper sweeps, a conveyor runs, a ride goes round — and none of that should mean copying the same blocks over and over. A loop says “do this again” once.
Blocks reference
| Block | What it does |
|---|---|
repeat (10) end | Runs the blocks inside a set number of times, then carries on below. |
forever end | Runs the blocks inside over and over, and never carries on below. |
repeat until <> end | Repeats until a condition becomes true — a loop with a sensor as its exit. |
Forever really does mean forever
Anything placed after a forever loop will never run. Not “runs late” — never. Both programs below end with the same block: set the status light green.
repeat (3)
repeat 3
A run clockwise for 0.25 rotations
set status light to green
forever
forever
A run clockwise for 0.25 rotations
set status light to green
↑ this block never runs
0passes · repeat (3)0passes · forever
repeat (3): still goingforever: light never set
Both loops begin. Each pass turns the motor a quarter turn.
Both programs contain the same green-light block. Let it run as long as you like — the right-hand ring will never turn green.
The repeat loop counts its three passes, stops, and moves on to the block underneath, so its light turns green. The forever loop reaches the bottom of its own blocks and jumps straight back to the top, so the block underneath is never reached — however long you leave it. If a program seems to stop half way through, look for a forever loop above the blocks that are not happening.
Why a sensor program needs a loop at all
A program is a list, and the Brick works down it once. Every block runs, in order, and when the last one is done the program is over. That is fine for a list of instructions — drive, turn, beep, stop — because each is a thing you do once.
A sensor is not a thing you do once. Asking is 1 pressed? gives you an answer about this instant, and an instant later it may be wrong. Checking a sensor once tells you what the world was like at the moment the program started — which is almost never what you wanted to know.
So a program that has to react must ask again, and again, for as long as it is running. That is the whole job of the loop: not to repeat an action, but to keep the question being asked.
Read, decide, act — and then do it again
Wrap a sensor check and the motor it controls in a forever loop and you have built a closed-loop control system — the pattern behind every line follower, thermostat and cruise control:
- Read the sensor.
- Decide what that reading means.
- Act on the motors.
- Go back to 1 — immediately, thousands of times a minute.
It is called closed because the output feeds back round to the input: the motors move the robot, moving the robot changes what the sensor sees, and what the sensor sees changes the motors. Break the circle at any point and the robot stops responding.
when program starts :: events hat
forever
if <[1 v] is pressed? :: sensors> then
[A v] start motor [clockwise v] :: motors
else
[A v] stop motor :: motors
end
endRead it as a sentence and it is almost too simple to need explaining: for ever, if the button is pressed run the motor, otherwise stop it. The motor now follows the button for as long as the program is running.
The same program without the loop
This is the mistake nearly everybody makes first, and it is a hard one to spot because nothing about it looks wrong:
when program starts :: events hat if <[1 v] is pressed? :: sensors> then [A v] start motor [clockwise v] :: motors else [A v] stop motor :: motors end
The logic is perfect. The ports are right. Nothing is misspelled. And the robot will ignore the button completely — because the Brick reaches that if/else a few milliseconds after you press Run, finds the button not pressed, takes the else branch, stops the motor, runs out of blocks and ends. By the time a finger arrives, there is no program left to notice it.
with forever — a closed loop
when program starts
forever
if 1 is pressed? then
A start motor clockwise
else
A stop motor
without it — the common mistake
when program starts
if 1 is pressed? then
A start motor clockwise
else
A stop motor
↑ running — for the only time
40checks · with forever1checks · no loop
Looped: motor off, matching the buttonNo loop: motor off for ever, whatever you press
Both programs start. The button is not pressed, so both take the else branch and leave the motor off. So far they agree exactly.
Both programs contain exactly the same if/else. The only difference is the forever block around one of them.
Both programs contain exactly the same if/else. The counter is what gives it away: one keeps checking for as long as it runs, the other is stuck on the single check it made before anybody touched anything. A student who has seen this once stops writing it.
The tell on a real robot is a program that ends the instant you start it — the Brick returns to its menu almost immediately. If a sensor program finishes rather than waits, the loop is what is missing.
Choosing the right loop
- Known number of times — repeat (n). A wiper that sweeps five times.
- Until something happens — repeat until. Drive until the wall is close.
- For as long as the machine is on — forever. A fan, a ride, a monitor.
The inner loop is one burst. The outer loop is how many bursts. Never confuse the two.
Degrees for part of a turnWhere the step size comes from — Lesson 4's cam, applied to a leg linkage.Show meHide
Moving to an exact angle
Everything so far has been relative: move 90 degrees from wherever you are now. Sometimes what you actually want is absolute: go to the 90-degree position, whatever position you happen to be in at the moment.
Relative drifts, absolute does not
Both pointers below do the same job over and over: swing out a quarter turn, then come home. The only difference is the block that brings them back. Watch one trip and they look identical — so let it run for several.
relative — by an amount
A run clockwise for 90 degrees
A run counterclockwise for 90 degrees
absolute — to a place
A run clockwise for 90 degrees
A run to position 0
0°relative, off home0°absolute, off home1trip
Relative: 0° from home and growingAbsolute: home, exactly
Both pointers are at home, on the black mark.
Let it loop. Nothing about the left program is wrong — it is just that every trip starts from wherever the last one finished, so a small error is never corrected, only added to.
A pointer moved relatively slowly wanders: each movement starts from wherever the last one finished, so any small error is carried forward and added to. Each orange dash is a trip that called a slightly different place “home”. Nothing about that program is wrong — it is simply that a relative move has no idea where it is supposed to end up.
An absolute movement has no memory of the error. Told to go to position 0, it goes to position 0 — the same place every time, however wrong it was beforehand. That makes it the right tool for a home position: the known place a mechanism returns to before it starts work.
Every motor knows where it is
This is possible because an EV3 motor counts its own turning all the time. Its position can be read back, and can be reset to zero — which is how you tell the motor that here is what you mean by zero, usually at the start of a program with the mechanism held at its resting place.
Why it matters
A clock hand returns to twelve; a car’s steering returns to centre; a 3D printer homes its head before every print. All of them go to a position rather than moving by an amount.
Say this back before moving on: “Inside the inner loop, the counts multiply.”
What’s in this build 4 min
| Part | What it is doing here |
|---|---|
| EV3 Intelligent Brick | The body. It is also most of the weight, and on a walking model that decides which legs actually grip. |
| Large Motor — the gait | Drives all eight legs through one linkage. One rotation is one complete step cycle, which is what makes 360 degrees mean “one step”. |
| The leg linkage (not electronic) | Puts the legs out of phase so some are always down. Look at it turning slowly — half the legs lift while the other half push. |
| The Brick screen and speaker | Count the dashes and the steps, so you can hear the nesting rather than having to trust it. |
Find what one step is
- Turn the motor slowly by hand through one full rotation and watch one particular leg. It should lift, swing, plant and push once.
- If the leg does two complete cycles per motor rotation, then one step is 180 degrees on your build, not 360. Use your number, not the one on this page.
- Check the spider does not rock — some legs must be down at every point in the cycle.
- Set it on a surface with some grip. On a polished table the legs scrabble and you will be debugging the floor.
Ports — and the rule 4 min
Sensors go in ports 1, 2, 3, 4. Motors go in ports A, B, C, D. They are not interchangeable, and nothing will tell you politely if you swap them.
| Part | Port | Why this one |
|---|---|---|
| Gait motor (Large) | A | One motor drives all eight legs, so there is exactly one thing to plug in. |
| Sensors | none | The spider walks blind. It stops because the program says to, not because it has seen anything — which is the opposite of the real animal, and worth noticing. |
Check your own build now:
- Motor in A.
- Route the cable up over the body so it does not get trodden on by the back legs.
- Clear a run of about half a metre. Twelve steps goes further than you think.
Connect the Brick 4 min
Two routes, and either is fine. USB is the reliable one and the one to fall back on when a room’s Bluetooth is busy; Bluetooth leaves the robot free to move, which some models need.
How to connect the BrickUSB and Bluetooth, step by step, with a photograph of every screen. Open it if you have not done this before — or if pairing is not working.Show meHide
USB — the reliable one
- Switch the Brick on with the dark grey centre button.
- Cable into the Brick’s PC port — the small square socket beside the numbered ports, not one of the numbered ones.
- Other end into the computer.
Bluetooth — name it first
Do these in order. Naming the Brick after you go looking for it in the list is how groups end up driving each other’s robots.
- Name your Brick. On the Brick: Settings (the spanner) → Brick Name. Type something nobody else will pick, then press the tick. Every Brick is called
EV3until somebody changes it. - Turn Bluetooth on. Settings → Bluetooth. Tick Bluetooth and Visibility. Leave iPhone/iPad/iPod unticked.
- Connect from EV3 Classroom. Click the Brick icon at the top of the programming area, find your Brick by name, and click Connect.
- Say yes on the Brick. It asks “Connect?” with the computer’s name — choose the tick, then accept the passkey, which is already 1234.
EV3.The two failures, every class, every time. The Brick has gone to sleep while you were building — press the centre button to wake it. Or you have paired with the group at the next table, which is why the name matters.
The long version, including Port View and how to read the port tiles, is in the Brick & Bluetooth guide.
Bluetooth. This one walks, and a cable trailing behind a legged model catches on its own back legs almost immediately.
Confirm the connection 2 min
- Check the Brick icon: connected, or not.
- One Large Motor tile on A.
- Turn the gait by hand through what you decided is one step and read tile A. That number is what goes in your motor block.
- Turn it three times and check the count is three times that — a quick way to confirm your step size before you build any loops on it.
Make it move 10 min
Four dashes of three steps each, with a pause between and the Brick counting both.
when program starts :: events hat
clear display :: display
write [LABAH-LABAH] at line (1) :: display
repeat (4)
write [Lari] at line (3) :: display
play beep (75) for (0.1) seconds :: sound
repeat (3)
[A v] run for (360) [degrees v] at (45) % speed :: motors
play beep (60) for (0.05) seconds :: sound
end
write [Diam] at line (3) :: display
wait (1) seconds
end
write [TAMAT] at line (5) :: display- The outer repeat (4) — four dashes. One pass of this loop is one burst of movement plus the pause after it.
- Lari and the high beep — inside the outer loop, above the inner one, so they happen four times: once at the start of each dash.
- The inner repeat (3) — three steps with a low beep each. These blocks run twelve times in all.
- Diam and the wait — inside the outer loop, below the inner one, so the spider goes still only after a complete dash. Four pauses, not twelve.
What success looks like: listen rather than watch. You should hear high, low-low-low, silence, four times over. If you hear a pause between every single step, the wait has ended up inside the inner loop.
Count the low beeps. There should be exactly twelve. If you hear a different number, the two loop counts are not what you think they are — and this is a much faster way to find that out than watching the legs.
Change it and test 8 min
Predict the total number of steps before every run, out loud, and count the low beeps to check. Getting the prediction right is the skill being tested.
- Change the inner loop to 6. Predict the total first — it is not 6, and it is not 10.
- Put it back to 3 and change the outer loop to 2. Predict again. Shorter journey, same dash.
- Move the
wait (1) secondsinside the inner loop. Run it. The spider now pauses after every step — the same blocks, in a different loop, giving a completely different animal. - Put the wait back and move the high beep inside the inner loop too. Now every step is announced as if it were a new dash, and the rhythm collapses.
- Make the dashes get longer: leave the loops alone but wrap the whole thing so the wait shrinks each time. If you cannot do it with the blocks you have, say exactly what you would need — you are describing a variable, and that is Level 3.
Steps 3 and 4 are the lesson. Nothing was added or deleted; a block moved from one loop to the other. The spider stopped looking like a spider, and the only thing that changed was how many times that block runs.
Which loop a block sits in is not a tidiness question. It decides how often it happens.
