Challenge 1
Hold station 20 cm from a wall for thirty seconds without hunting back and forth.
What you are building 3 min
The Dragon Boat: a long hull with a carved dragon’s head at the bow — and the head is an Ultrasonic Sensor. Two motors drive the paddles through gears.
Both motors are joined to the same axle. They cannot turn independently, so this boat cannot steer at all. Forwards and backwards are the only two things it can do.
By the end of the lesson the boat will hold its position in front of a wall — moving up when it drifts back, backing off when it gets too close, and sitting still when it is right.
In the real world 5 min
Where you have seen it
Dragon boat racing is a festival sport across Malaysia — Penang, Kuching, Putrajaya. Twenty paddlers, one drummer at the bow, one steersman at the stern, and a boat that goes nowhere unless everybody pulls together.
Why it is built that way
The drummer is not entertainment. Twenty paddles out of time cancel each other out — one crew member pulling while another recovers puts the boat into a wallow. The drum is a shared clock, and it is the same job the gears on your axle are doing: forcing everything to agree.
Now the part that matters today. Watch a race start. The boats are held on the line against wind and current, and they are not held by stopping. Water moves them, so the crews take small strokes forward and small backing strokes, constantly, in both directions, until the gun.
Ships do this automatically. A supply vessel beside an oil rig uses dynamic positioning: computers reading the ship’s position and running thrusters to push it back — forward, back, sideways, all day, in a swell. It is never still, and it never moves.
What would go wrong without it
Lesson 43’s Skiing Robot could only ever slow down. If it overshot, it had no way back — approaching is a one-way problem, and holding is not.
To stay somewhere you must be able to go both ways. Otherwise you can only arrive.
The main concept — which way, and when not to bother 6 min
You want the boat to sit 20 cm from the wall. There are three situations, not two, and the third one is the interesting one.
| Reading | Meaning | Do |
|---|---|---|
| more than 25 cm | too far back | paddle forward |
| 15 to 25 cm | close enough | nothing at all |
| less than 15 cm | too close | back water |
if <([4 v] distance in [cm v] :: sensors) > (25)> then
move [forward v] for (0.3) [rotations v] at (30) % speed :: movement
else
if <([4 v] distance in [cm v] :: sensors) < (15)> then
move [backward v] for (0.3) [rotations v] at (30) % speed :: movement
else
stop moving :: movement
end
endYou have nested a loop inside a loop back in Lesson 20. This is the same move with Switches, and it is how a program picks between three outcomes when each block only offers two.
The dead band, and why the boat needs one
The obvious version has no middle: forward above 20, backward below 20. Try it and the boat never stops. It nudges forward, overshoots past 20, nudges back, overshoots again — hunting, for ever, getting through batteries and going nowhere.
The gap from 15 to 25 is a dead band: a zone where the correct action is to take no action. It is not laziness; it is what lets the machine settle.
| Dead band | What the boat does |
|---|---|
| none (a single line at 20) | hunts for ever. Never wrong for long, never right either |
| narrow (19–21) | still twitchy — one nudge overshoots the whole band |
| sensible (15–25) | settles and holds. Corrects only when it has really drifted |
| huge (5–50) | settles instantly, and holds position very badly |
The band has to be wider than one correction step. That is the rule. If a 0.3-rotation nudge moves the boat 8 cm, a band of 4 cm cannot possibly hold it — every correction throws it out the other side. Measure your nudge before you choose your band.
Where this sits next to yesterday
Lesson 43 worked out how much to do, from how far away the wall was. Today works out which way to do it, from which side of the target you are on. Put the two together and you have most of a real controller — which is what Level 4 builds a whole block around.
Making a decision
Up to now a robot has been able to wait for a sensor. Deciding is different: the robot checks the sensor and does one thing or another depending on the answer — and then carries on either way.
Blocks reference
| Block | What it does |
|---|---|
if <> then end | Runs the blocks inside only when the condition is true. Otherwise skips them. |
if <> then else end | Runs one set of blocks when true and a different set when false. |
Deciding again and again
A decision made once, at the start, is almost never what you want. Here are two robots with the identical if-else, testing the identical sensor against the identical number — one inside a loop and one not.
decision inside a loop
forever
if distance < 15 then
stop moving
else · start moving
the same decision, once
if distance < 15 then
stop moving
else · start moving
247checks · in a loop1check · once only
Nothing is close, so both robots ask «is the wall within 15 cm?», both hear no, and both take the else branch and drive.
A decision is only worth as much as the last time it was made. Inside a loop, that is a few milliseconds ago.
Nothing is wrong with the right-hand program’s decision. It asked the question, got a truthful answer, and acted on it correctly. It simply never asked again, and the world moved on. Decisions belong inside a loop, so the robot keeps re-deciding as things change.
when program starts :: events hat
forever
if <([4 v] distance in [cm v] :: sensors) < (15)> then
stop moving :: movement
else
start moving [straight: 0] :: movement
end
endFour shapes, and how to choose
Once there is more than one question, decisions can be arranged in four ways. They look nearly identical stacked up in the editor, which is exactly why they get muddled — the thing that differs is not what the blocks say, it is which routes through them exist.
One question sorts them almost completely:
| Are the questions… | Use | How many bodies can run |
|---|---|---|
| independent — any combination can be true | separate ifs | none, some, or all |
| one question, two answers | if / else | exactly one |
| the second only matters when the first is true | nested if | one, and only via the outer |
| mutually exclusive cases — exactly one should win | chained if / else | exactly one, the first that matches |
Separate ifs — independent questions
Each if is asked no matter what the others answered, so any number of them can fire on the same pass. That is the right shape when the conditions genuinely have nothing to do with each other.
forever
if <[3 v] is ambient light intensity [< v] (20) %? :: sensors> then
[A v] start motor [clockwise v] :: motors
end
if <[4 v] is distance [< v] (15) [cm v]? :: sensors> then
[D v] start motor [clockwise v] :: motors
end
endif / else — one question, two answers
Exactly one branch runs, every time. Reach for this whenever the robot must do something either way — and in preference to two ifs testing opposite conditions, which is the same idea written twice and can drift apart.
Nested if — a follow-up question
Putting one if inside another means the inner question is only ever asked when the outer one is true. Use it when the second question is meaningless otherwise: there is no point asking which side an obstacle is on when there is no obstacle.
if <[4 v] is distance [< v] (15) [cm v]? :: sensors> then
if <([2 v] angle :: sensors) < (0)> then
start moving [right: 50] :: movement
end
endWhen not to nest. If you only want “both true” and nothing happens at the outer level, an and says it in one block and reads better:
if <<[4 v] is distance [< v] (15) [cm v]? :: sensors> and <([2 v] angle :: sensors) < (0)>> then start moving [right: 50] :: movement end
Nesting earns its place when something happens at the outer level too, or when there is an else at each level and the two mean different things.
Chained if / else — one winner out of several
This is the shape for a list of cases where exactly one should win: colour bands, distance bands, speed ranges. EV3 Classroom has no else-if block, so you build a chain by putting the next if inside the else of the last one.
And here is why it matters, because this is the single commonest bug in this whole module. Three bands written as three separate ifs are each perfectly correct, and together they are wrong: a reading of 20 is under 30 and under 60 and under 90, so all three run and the last one to run is the one that sticks.
three separate ifs
if light < 30 then
stop
if light < 60 then
go slowly
if light < 90 then
go fast
chained — if / else / if
if light < 30 then
stop
else
if light < 60 then
go slowly
else
go fast
↑ the rest is inside the else — never asked
3bands matchedgo fastseparate ifs dostopchained does
Separate ifs: 3 matched, last one winsChained: first match wins, rest never asked
The sensor reads 20 — a dark surface. Both programs should stop.
Separate ifs are not wrong here so much as unguarded: nothing stops a second one matching. Chaining is what makes “the first one wins” true.
The rule to carry away: if the cases are meant to be exclusive, they must be made exclusive. Chaining does it by construction. Separate ifs only work if you are careful to write non-overlapping bands yourself — light < 30, 30 to 60, 60 and over — which is more to get right and easy to break later.
Why it matters
This is the point at which a machine stops following a script and starts responding. A thermostat, an automatic door, a robot vacuum — all of them are a decision inside a loop.
The Ultrasonic Sensor
The Ultrasonic Sensor measures distance. It sends out a burst of sound too high for people to hear, listens for the echo, and works out how far away the surface is from how long the echo took — exactly how a bat finds a moth, and how a submarine uses sonar.
front
sideBlocks reference
| Block | What it does |
|---|---|
([4 v] distance in [cm v] :: sensors) | Reports how far away the nearest thing in front of the sensor is, as a number in centimetres. |
wait until <([4 v] distance in [cm v] :: sensors) < (15)> | Holds the program until something comes closer than 15 cm. |
A number, not a yes or no
This is the important step up from the Touch Sensor. Touch gives you true or false; the Ultrasonic gives you a number, and the deciding is left to you. Pick a threshold below and watch where the robot ends up.
when program starts
start moving straight: 0
4 wait until distance < 15 cm
stop moving
60cm · reading15cm · threshold
Nothing is close. The sensor reports about 60 cm and the program waits.
The black line on the bar is the threshold; the blue fill is the reading. The robot stops the instant the fill crosses the line.
Three different robots, and only one number is different between them. That is what having a number rather than a yes-or-no buys you: the behaviour is tuned by editing one slot, not by rebuilding the program. It also means the sensor can never tell you it is “close” — close is a decision you make about a reading.
Why it matters
Car parking sensors, automatic doors at a shopping centre, and the sensor that stops a lift door closing on somebody all work this way. Reacting before contact is what makes a machine feel safe.
If your set has an Infrared Sensor instead
The Home/Retail EV3 set (31313) ships an Infrared Sensor and a Beacon in place of the Ultrasonic and Gyro sensors. The Infrared Sensor also measures distance, so the programs in this module work with it — but it reports a rough 0–100 proximity rather than real centimetres, and it is affected by sunlight and by dark surfaces in ways the Ultrasonic is not.
IR Sensor
BeaconToo far, too close, or near enough. The third one is what stops the hunting.
A loop inside a loopFrom Lesson 20 — nesting, and reading a program from the inside out.Show meHide
Repeating
Machines repeat. A wiper sweeps, a conveyor runs, a ride goes round — and none of that should mean copying the same blocks over and over. A loop says “do this again” once.
Blocks reference
| Block | What it does |
|---|---|
repeat (10) end | Runs the blocks inside a set number of times, then carries on below. |
forever end | Runs the blocks inside over and over, and never carries on below. |
repeat until <> end | Repeats until a condition becomes true — a loop with a sensor as its exit. |
Forever really does mean forever
Anything placed after a forever loop will never run. Not “runs late” — never. Both programs below end with the same block: set the status light green.
repeat (3)
repeat 3
A run clockwise for 0.25 rotations
set status light to green
forever
forever
A run clockwise for 0.25 rotations
set status light to green
↑ this block never runs
0passes · repeat (3)0passes · forever
repeat (3): still goingforever: light never set
Both loops begin. Each pass turns the motor a quarter turn.
Both programs contain the same green-light block. Let it run as long as you like — the right-hand ring will never turn green.
The repeat loop counts its three passes, stops, and moves on to the block underneath, so its light turns green. The forever loop reaches the bottom of its own blocks and jumps straight back to the top, so the block underneath is never reached — however long you leave it. If a program seems to stop half way through, look for a forever loop above the blocks that are not happening.
Why a sensor program needs a loop at all
A program is a list, and the Brick works down it once. Every block runs, in order, and when the last one is done the program is over. That is fine for a list of instructions — drive, turn, beep, stop — because each is a thing you do once.
A sensor is not a thing you do once. Asking is 1 pressed? gives you an answer about this instant, and an instant later it may be wrong. Checking a sensor once tells you what the world was like at the moment the program started — which is almost never what you wanted to know.
So a program that has to react must ask again, and again, for as long as it is running. That is the whole job of the loop: not to repeat an action, but to keep the question being asked.
Read, decide, act — and then do it again
Wrap a sensor check and the motor it controls in a forever loop and you have built a closed-loop control system — the pattern behind every line follower, thermostat and cruise control:
- Read the sensor.
- Decide what that reading means.
- Act on the motors.
- Go back to 1 — immediately, thousands of times a minute.
It is called closed because the output feeds back round to the input: the motors move the robot, moving the robot changes what the sensor sees, and what the sensor sees changes the motors. Break the circle at any point and the robot stops responding.
when program starts :: events hat
forever
if <[1 v] is pressed? :: sensors> then
[A v] start motor [clockwise v] :: motors
else
[A v] stop motor :: motors
end
endRead it as a sentence and it is almost too simple to need explaining: for ever, if the button is pressed run the motor, otherwise stop it. The motor now follows the button for as long as the program is running.
The same program without the loop
This is the mistake nearly everybody makes first, and it is a hard one to spot because nothing about it looks wrong:
when program starts :: events hat if <[1 v] is pressed? :: sensors> then [A v] start motor [clockwise v] :: motors else [A v] stop motor :: motors end
The logic is perfect. The ports are right. Nothing is misspelled. And the robot will ignore the button completely — because the Brick reaches that if/else a few milliseconds after you press Run, finds the button not pressed, takes the else branch, stops the motor, runs out of blocks and ends. By the time a finger arrives, there is no program left to notice it.
with forever — a closed loop
when program starts
forever
if 1 is pressed? then
A start motor clockwise
else
A stop motor
without it — the common mistake
when program starts
if 1 is pressed? then
A start motor clockwise
else
A stop motor
↑ running — for the only time
40checks · with forever1checks · no loop
Looped: motor off, matching the buttonNo loop: motor off for ever, whatever you press
Both programs start. The button is not pressed, so both take the else branch and leave the motor off. So far they agree exactly.
Both programs contain exactly the same if/else. The only difference is the forever block around one of them.
Both programs contain exactly the same if/else. The counter is what gives it away: one keeps checking for as long as it runs, the other is stuck on the single check it made before anybody touched anything. A student who has seen this once stops writing it.
The tell on a real robot is a program that ends the instant you start it — the Brick returns to its menu almost immediately. If a sensor program finishes rather than waits, the loop is what is missing.
Choosing the right loop
- Known number of times — repeat (n). A wiper that sweeps five times.
- Until something happens — repeat until. Drive until the wall is close.
- For as long as the machine is on — forever. A fan, a ride, a monitor.
Say this back before moving on: “Close enough is an answer, and it is usually the right one.”
What’s in this build 4 min
Look at your boat. Follow the axle from one motor to the other. It is the most important thing in this build, and it is not electronic.
| Part | What it is doing here |
|---|---|
| EV3 Intelligent Brick | The hull. Long and low, like the real thing. |
| Large Motor ×2 — the paddles | Geared to one shared axle, so they must turn together. This is Level 1’s shared-axle lesson: agree and you get twice the force; disagree and something gives. |
| Ultrasonic Sensor — the dragon’s head | Right at the bow, which is exactly where you want it: it measures the gap the boat is trying to hold. |
| The shared axle and gears (not electronic) | The reason this boat cannot steer — and the reason it can push twice as hard in a straight line. |
Measure your nudge before you pick your band
- Put the boat on your surface, mark the bow’s position, and run one move [forward v] for (0.3) [rotations v].
- Measure how far it moved. That is your correction step.
- Your dead band must be wider than twice that. If a nudge is 5 cm, a 10 cm band (15–25) is right, and a 4 cm band is impossible.
- Check the boat runs straight when pushed. It cannot steer, so a boat that wanders will slide out of the sensor’s view and never come back.
Ports — and the rule 4 min
Sensors go in ports 1, 2, 3, 4. Motors go in ports A, B, C, D. They are not interchangeable, and nothing will tell you politely if you swap them.
| Part | Port | Why this one |
|---|---|---|
| Left paddle motor | B | The pair. Two motors, one shaft, one job. |
| Right paddle motor | C | The other half. |
| Dragon’s head (Ultrasonic) | 4 | The Ultrasonic’s standing home. |
Get B and C the right way round, or the motors will fight. On a shared axle a reversed motor does not make the boat turn — it makes two motors pull against each other through the gears, which stalls both and strains the plastic. Level 1’s Lift Simulation made this point and it is more serious here.
The manual wires this boat to A and D, with the Ultrasonic Sensor in port 2. This lesson uses B and C for the pair and 4 for the Ultrasonic, which is where they live everywhere else in the course. Three cables. Move them, or change the ports in every program — and if you keep port 2, remember it is the Gyro’s usual slot, which this model does not have.
Check your own wiring now:
- Paddles in B and C, head in 4.
- Test both motors together at low speed first, off the table, and listen. Straining or clicking means one is reversed. Stop immediately.
- Cables out of the paddles’ sweep, and off the running surface.
- Head aimed level at the wall, not down at the table.
Connect the Brick 4 min
Two routes, and either is fine. USB is the reliable one and the one to fall back on when a room’s Bluetooth is busy; Bluetooth leaves the robot free to move, which some models need.
How to connect the BrickUSB and Bluetooth, step by step, with a photograph of every screen. Open it if you have not done this before — or if pairing is not working.Show meHide
USB — the reliable one
- Switch the Brick on with the dark grey centre button.
- Cable into the Brick’s PC port — the small square socket beside the numbered ports, not one of the numbered ones.
- Other end into the computer.
Bluetooth — name it first
Do these in order. Naming the Brick after you go looking for it in the list is how groups end up driving each other’s robots.
- Name your Brick. On the Brick: Settings (the spanner) → Brick Name. Type something nobody else will pick, then press the tick. Every Brick is called
EV3until somebody changes it. - Turn Bluetooth on. Settings → Bluetooth. Tick Bluetooth and Visibility. Leave iPhone/iPad/iPod unticked.
- Connect from EV3 Classroom. Click the Brick icon at the top of the programming area, find your Brick by name, and click Connect.
- Say yes on the Brick. It asks “Connect?” with the computer’s name — choose the tick, then accept the passkey, which is already 1234.
EV3.The two failures, every class, every time. The Brick has gone to sleep while you were building — press the centre button to wake it. Or you have paired with the group at the next table, which is why the name matters.
The long version, including Port View and how to read the port tiles, is in the Brick & Bluetooth guide.
Bluetooth. This boat is trying to hold a position to within a few centimetres, and a cable is a spring pulling it one way. It will hold station perfectly — at the wrong distance, and only until somebody moves the laptop.
Confirm the connection 2 min
- Check the Brick icon: connected, or not.
- Two motor tiles on B and C, and an Ultrasonic tile on 4.
- Slide the boat by hand and watch tile 4. Find the spot where it reads 20. Mark it with tape — that is where the boat should end up, and having it marked makes success visible.
- Now check tile 4 at your two thresholds, 15 and 25, and mark those too. You now have the dead band drawn on the table.
Stuck? The long version, with a photograph of every screen, is in the Brick & Bluetooth guide.
Make it move 10 min
Hold station 20 cm off the wall, whatever anybody does to the boat.
when program starts :: events hat
set movement motors to [B v] and [C v] :: movement
clear display :: display
forever
write ([4 v] distance in [cm v]) at line (1) :: display
if <([4 v] distance in [cm v] :: sensors) > (25)> then
write [MAJU ] at line (3) :: display
move [forward v] for (0.3) [rotations v] at (30) % speed :: movement
else
if <([4 v] distance in [cm v] :: sensors) < (15)> then
write [UNDUR ] at line (3) :: display
move [backward v] for (0.3) [rotations v] at (30) % speed :: movement
else
write [TAHAN ] at line (3) :: display
stop moving :: movement
end
end
end- The
forevernever ends, and it should not. Holding station is not a task that finishes; it is a thing the machine does until told otherwise. - One nudge per pass. Small corrections, checked often — Lesson 35’s stride argument again. A big correction cannot be held back once it has started.
- The trailing spaces matter.
MAJUhas to be as long asUNDUR, or a leftover letter stays on screen — the display only overwrites the characters it is given. - The
elsebranch says TAHAN and stops. Doing nothing is a real decision here, and showing it proves the boat is holding rather than hung.
What success looks like: put the boat down anywhere. It paddles up or backs off, then settles between your two tape marks and stops, with TAHAN on the screen. Now move the wall closer — a book slid in by hand — and it backs away and settles again.
If it never stops nudging, your dead band is narrower than your correction step — go back to step 5 and measure. If it strains and does not move, one motor is reversed on the shared axle; stop and fix the port.
Change it and test 8 min
One change at a time. The good test here is to be a nuisance: move the wall, push the boat, and see whether it recovers.
- Close the dead band to 19 and 21. Run it. The boat hunts and never settles — and now you have seen why the band exists rather than been told.
- Widen it to 5 and 50. It settles instantly and holds station terribly. Both extremes are wrong in different ways.
- Put 15 and 25 back and halve the nudge to 0.15 rotations. Can you now narrow the band to 17 and 23 and still have it settle? Smaller corrections buy a tighter band.
- Move the wall slowly towards the boat and watch it back away, keeping station. This is a following robot, and you did not program following.
- Now move the wall quickly. It falls behind. What is the fastest wall it can keep up with, and what limits it — the nudge size or the speed?
- Bring in Lesson 43: replace the fixed 30% speed with a speed that grows with how far out it is. The boat should now correct a big drift quickly and a small one gently.
Step 6 is where the two lessons join. Which way to go comes from the sign of the error; how hard to go comes from its size. A controller that has both is doing everything a proportional controller does, and you built it from an if, a nested if and a multiplication.
A machine that can only approach will arrive once. A machine that can correct both ways can stay.
