Challenge 1
Prove the interlock. Attempt to fire unarmed and show the refusal, then arm and fire successfully.
What you are building 3 min
The Archery Robot: a driving base carrying a bow. One Medium Motor draws the bow and holds it; a second Medium Motor lets it go.
Four motors, three jobs. Two drive it to the shooting line, one arms it, one shoots. The arming and the shooting are deliberately separate, which is how every serious machine that stores energy is built.
By the end of the lesson the release will physically refuse to fire a bow that is not drawn — and it will tell you why it refused.
Safety, before anything else. This model launches a beam. Point it at a wall or a cardboard box, never at a person, an animal or a window. Everybody within two metres wears eye protection. One rule, no exceptions, all lesson.
In the real world 5 min
Where you have seen it
Every archery range in the world runs on the same rules, and they are not suggestions. Arrows are not nocked until the whistle. Nobody crosses the line until the whistle. A single blast means shoot; two mean go and collect; five or more mean stop immediately, whatever you are doing.
Why it is built that way
A drawn bow is a great deal of stored energy waiting for one small event. A modern compound bow holds tens of kilograms of draw, and its whole design is about making that energy easy to hold and hard to release by accident.
So the range does not rely on everybody being careful. It makes the dangerous thing impossible at the wrong moment — no arrow on the string, no archer past the line, and one signal everybody obeys. Rules that depend on nobody making a mistake are not safety rules; they are hopes.
What would go wrong without it
Lesson 41’s Chu Ko Nu could not get its order wrong — the peg could not reach the string until the lever had come far enough, so the sequence was guaranteed by the shape of the parts.
This machine has no such guarantee. Its release motor will happily fire an undrawn bow, and the program is the only thing standing between the two.
When the mechanism cannot make a mistake impossible, the program has to.
The main concept — a step that can refuse 6 min
An interlock is a check that guards a dangerous or irreversible step. It is not there to make the machine clever. It is there so a mistake produces nothing instead of producing a disaster.
if <<(sedia) = (1)> and <([A v] degrees counted) > (300)>> then [D v] run [clockwise v] for (0.5) [rotations v] at (100) % speed :: motors set [sedia v] to (0) else play beep (45) for (0.5) seconds :: sound write [DITOLAK] at line (3) :: display end
Two conditions, and they are not the same kind of thing
This is what makes the interlock strong, and it is worth slowing down for.
| Condition | What it really is | Can it be wrong? |
|---|---|---|
(sedia) = (1) | The program’s belief. It was set when the arm stack ran. | Yes. If somebody un-draws the bow by hand, the variable still says 1 |
([A v] degrees counted) > (300) | The machine’s evidence. The draw motor really is that far round. | Much harder. This is a measurement of the actual mechanism |
Lesson 33 ended on exactly this problem. The rifle’s ammunition count was what the machine believed, and reaching into the magazine by hand made the belief false with nothing to notice. This is the answer: check the belief and check the world, and join them with and.
Three rules for an interlock worth having
- Guard the irreversible step, not the harmless ones. The release gets a guard. Driving does not — you can always drive back.
- Refuse audibly. Lesson 28’s crane rule. A control that silently does nothing is indistinguishable from a broken one, and a person who thinks a control is broken starts looking for another way to make it work.
- Clear the state after acting.
set [sedia] to (0)is in the then branch, and it matters: the bow has been fired, so it is no longer armed. Forget that and a second press fires an empty bow with the program’s blessing.
You have all four pieces already
The and is Lesson 17. The state variable is Lesson 34. The encoder reading is Lesson 8. The audible refusal is Lesson 28. Nothing here is a new block — the lesson is the arrangement, and the arrangement is what makes a machine safe to hand to somebody else.
Making a decision
Up to now a robot has been able to wait for a sensor. Deciding is different: the robot checks the sensor and does one thing or another depending on the answer — and then carries on either way.
Blocks reference
| Block | What it does |
|---|---|
if <> then end | Runs the blocks inside only when the condition is true. Otherwise skips them. |
if <> then else end | Runs one set of blocks when true and a different set when false. |
Deciding again and again
A decision made once, at the start, is almost never what you want. Here are two robots with the identical if-else, testing the identical sensor against the identical number — one inside a loop and one not.
decision inside a loop
forever
if distance < 15 then
stop moving
else · start moving
the same decision, once
if distance < 15 then
stop moving
else · start moving
247checks · in a loop1check · once only
Nothing is close, so both robots ask «is the wall within 15 cm?», both hear no, and both take the else branch and drive.
A decision is only worth as much as the last time it was made. Inside a loop, that is a few milliseconds ago.
Nothing is wrong with the right-hand program’s decision. It asked the question, got a truthful answer, and acted on it correctly. It simply never asked again, and the world moved on. Decisions belong inside a loop, so the robot keeps re-deciding as things change.
when program starts :: events hat
forever
if <([4 v] distance in [cm v] :: sensors) < (15)> then
stop moving :: movement
else
start moving [straight: 0] :: movement
end
endFour shapes, and how to choose
Once there is more than one question, decisions can be arranged in four ways. They look nearly identical stacked up in the editor, which is exactly why they get muddled — the thing that differs is not what the blocks say, it is which routes through them exist.
One question sorts them almost completely:
| Are the questions… | Use | How many bodies can run |
|---|---|---|
| independent — any combination can be true | separate ifs | none, some, or all |
| one question, two answers | if / else | exactly one |
| the second only matters when the first is true | nested if | one, and only via the outer |
| mutually exclusive cases — exactly one should win | chained if / else | exactly one, the first that matches |
Separate ifs — independent questions
Each if is asked no matter what the others answered, so any number of them can fire on the same pass. That is the right shape when the conditions genuinely have nothing to do with each other.
forever
if <[3 v] is ambient light intensity [< v] (20) %? :: sensors> then
[A v] start motor [clockwise v] :: motors
end
if <[4 v] is distance [< v] (15) [cm v]? :: sensors> then
[D v] start motor [clockwise v] :: motors
end
endif / else — one question, two answers
Exactly one branch runs, every time. Reach for this whenever the robot must do something either way — and in preference to two ifs testing opposite conditions, which is the same idea written twice and can drift apart.
Nested if — a follow-up question
Putting one if inside another means the inner question is only ever asked when the outer one is true. Use it when the second question is meaningless otherwise: there is no point asking which side an obstacle is on when there is no obstacle.
if <[4 v] is distance [< v] (15) [cm v]? :: sensors> then
if <([2 v] angle :: sensors) < (0)> then
start moving [right: 50] :: movement
end
endWhen not to nest. If you only want “both true” and nothing happens at the outer level, an and says it in one block and reads better:
if <<[4 v] is distance [< v] (15) [cm v]? :: sensors> and <([2 v] angle :: sensors) < (0)>> then start moving [right: 50] :: movement end
Nesting earns its place when something happens at the outer level too, or when there is an else at each level and the two mean different things.
Chained if / else — one winner out of several
This is the shape for a list of cases where exactly one should win: colour bands, distance bands, speed ranges. EV3 Classroom has no else-if block, so you build a chain by putting the next if inside the else of the last one.
And here is why it matters, because this is the single commonest bug in this whole module. Three bands written as three separate ifs are each perfectly correct, and together they are wrong: a reading of 20 is under 30 and under 60 and under 90, so all three run and the last one to run is the one that sticks.
three separate ifs
if light < 30 then
stop
if light < 60 then
go slowly
if light < 90 then
go fast
chained — if / else / if
if light < 30 then
stop
else
if light < 60 then
go slowly
else
go fast
↑ the rest is inside the else — never asked
3bands matchedgo fastseparate ifs dostopchained does
Separate ifs: 3 matched, last one winsChained: first match wins, rest never asked
The sensor reads 20 — a dark surface. Both programs should stop.
Separate ifs are not wrong here so much as unguarded: nothing stops a second one matching. Chaining is what makes “the first one wins” true.
The rule to carry away: if the cases are meant to be exclusive, they must be made exclusive. Chaining does it by construction. Separate ifs only work if you are careful to write non-overlapping bands yourself — light < 30, 30 to 60, 60 and over — which is more to get right and easy to break later.
Why it matters
This is the point at which a machine stops following a script and starts responding. A thermostat, an automatic door, a robot vacuum — all of them are a decision inside a loop.
Reading a motor's position
Every EV3 motor contains a sensor that counts how far it has actually turned. That means a motor is not only an output — you can ask it where it is, and the answer describes what really happened rather than what you asked for.
Blocks reference
| Block | What it does |
|---|---|
([A v] degrees counted :: sensors) | Reports how far this motor has actually turned since the count was last reset, in degrees. |
[A v] reset degrees counted :: motors | Sets the count back to zero, making right here the new reference point. |
([A v] speed :: sensors) | Reports how fast the motor is turning right now, as a percentage. A motor that is being driven but reads zero is a motor that is stuck. |
Asked for, versus achieved
Those two are not always the same. Here are two identical motors, running the same program, with only their mechanisms different.
when program starts
A reset degrees counted
A run clockwise for 2 rotations
write A degrees counted at line 1
the same program, on two identical motors
720degrees asked for0counted · free0counted · jammed
Free: asked 720, counted 720Jammed: asked 720, counted 0
Both motors are told to turn two rotations — 720 degrees. Both counters start at zero.
Nothing on the Brick announces a stall. The only evidence is that the counter stopped changing while the motor was still being told to turn.
Nothing on the Brick announces the jam. The motor is still being driven, the program is still sitting on the same block, and the only trace of the problem anywhere is a counter that has stopped climbing. Comparing what you asked for with what was counted is how a robot notices — which is the whole of stall detection.
Zero is wherever you say it is
When the Brick powers on, the count is simply whatever it happens to be. It is not a position on the machine — it becomes one only when you tie it to something physical.
That is what reset degrees counted is for, and it is not just a tidy-up block for the top of a program. Where you put it decides what zero means, so putting it part-way through — after the mechanism has been driven somewhere known — is the normal way to use it, not an abuse of it.
Find home first, then reset
A conveyor has no idea where it is. Give it a touch sensor at one end and it can find out: drive it until the sensor is pressed, and it is now at a place you can name. Only then reset the count, and that end becomes 0.
when program starts :: events hat [A v] start motor [counterclockwise v] :: motors [1 v] wait until [pressed v] :: sensors [A v] stop motor :: motors [A v] reset degrees counted :: motors
The order is the whole point. Reset before the sensor is pressed and you have zeroed a random spot; reset after it, and every later reading means “how far from home”. This is called homing, and it is why a printer rattles its head to one side when you switch it on.
Drive towards home gently. The mechanism is deliberately being run into its own end stop, so a slow speed saves the gears — and the touch sensor is what stops it, which means it stops in the same place every time regardless of where it started.
Putting zero somewhere more useful
Home is often a corner, and a corner is an awkward place to measure from. Say the conveyor carries a chute that dispenses bricks, and you would rather describe its position as left and right of the middle. Then home once, drive the known distance to the middle, and reset again there:
when program starts :: events hat [A v] start motor [counterclockwise v] :: motors [1 v] wait until [pressed v] :: sensors [A v] stop motor :: motors [A v] reset degrees counted :: motors [A v] run [clockwise v] for (900) [degrees v] :: motors [A v] reset degrees counted :: motors
Now the middle is 0. Moving right counts up, moving left counts down past zero into negative numbers — the count is perfectly happy to go negative — and “go back to the middle” becomes the simplest instruction in the program: drive until the count reaches 0.
Both resets earn their place. The first one turns a meaningless number into a distance from a real, repeatable place. The second one moves zero to where the maths is easiest. A reset in the middle of a program is only a mistake when the mechanism is somewhere you cannot name.
Turning turns into distance
Because the count is in degrees, and a wheel of known size travels a known distance per turn, the reading can be converted into how far the robot has actually driven. That is how a robot reports a distance in centimetres rather than in rotations — and it is why changing the wheels changes the answer.
Why it matters
This is how a printer knows the paper jammed, how a car window stops when it meets your hand, and how a robot arm knows it has reached its limit. A machine that can only give orders is fragile; one that can check what happened can recover.
Guard the step you cannot undo. Check what you believe and what you can measure, and refuse out loud.
`and` — both, not eitherFrom Lesson 14 — the Forklift's condition, and the truth table.Show meHide
Comparing and combining
A sensor that reports a number cannot be used to make a decision on its own — 23 is neither true nor false. An operator turns that number into an answer by comparing it with something.
Blocks reference
| Block | What it does |
|---|---|
<(x) > (50)> | True when the left value is bigger than the right. |
<(x) < (50)> | True when it is smaller. |
<<> and <>> | True only when both conditions are true. |
<<> or <>> | True when at least one of them is. |
Try it: which way round does it go?
Forget the symbols for a moment. A comparison is a question about position on a number line: is x to the left of the other number, or to the right? Left is smaller, right is bigger — and that is the whole of it.
Drag the orange x and the black marker, and change the comparison. The green stretch is every position of x that would make the answer true — so you can see where the answer flips before you get there. Turn not on and watch the green jump to the other side.
Drag either marker, or use the arrow keys.
-3 < 4true
is x to the LEFT of it?
- < is true while x sits on the left. Slide x past the marker and it flips.
- > is the same question the other way round — so exactly one of the two is true, unless the markers are on the same spot.
- = is true for one single position out of twenty-one. Try landing on it. That is why a sensor is almost never compared with =: a reading passes straight through the exact number without ever being measured there.
- not flips the answer, whatever it was. not (x < 4) covers everything x < 4 does not — including landing exactly on 4.
Try it: which numbers make it true?
The lab above asks one question at a time: is this x true? A robot never has just one x, though — a sensor reading slides up and down all the time, so what really matters is which stretch of the line makes the condition true. This one draws the whole answer at once.
Drag the circle to move the number you are comparing against, and change the comparison. Everything shaded green is a value of x that would make it true.
Drag the circle, or use the arrow keys. It moves in steps of 0.2.
x < 0.2x < 0.2
Every number to the left of 0.2 — but not 0.2 itself, so the circle is hollow.
Watch the circle, because it carries the part everyone gets wrong:
- Hollow ○ — the boundary is not included. x < 0.2 shades everything left of 0.2 but leaves 0.2 itself out, because 0.2 is not less than 0.2.
- Filled ● — the boundary is included. Choose = and nothing is shaded at all: one single number qualifies.
Now turn not on with x > 2 selected and watch two things happen together. The shading jumps to the other side, and the circle fills in — because “not greater than 2” means 2 or less, and 2 has to be part of it. That pairing is the whole reason a hollow circle is worth drawing.
Why a robot cares. Two conditions that look almost identical — light < 30 and not (light > 30) — differ by exactly one value, the reading of precisely 30. A robot sitting right on its threshold behaves differently under the two, and that is the sort of bug that only shows up occasionally and looks like a broken sensor.
Try it: and, or, not
These three join answers together rather than numbers. The trap is that English is looser than a program: “stop if it is close and the bumper is pressed” sounds like it covers both situations, when it covers neither on its own.
Flip the two conditions and watch the table. There are only four possible situations in total, and and and or differ on exactly two of them.
close: true and bumper: falsefalse
| close | bumper | and | or |
|---|---|---|---|
| true | true | true | true |
| true | false | false | true |
| false | true | false | true |
| false | false | false | false |
and is fussy: it wants both. Three of the four rows are false.
- and is true on one row out of four. It narrows — the robot acts less often, but more certainly.
- or is true on three rows out of four. It widens — the robot acts more readily.
- The two agree on the top and bottom rows and disagree in the middle. Whenever swapping one for the other seems to make no difference, you have only tried the rows where they agree.
Watch them decide
Two sensors are running below: an Ultrasonic reporting a number, and a Touch Sensor reporting true or false. Watch the comparison turn the number into an answer, and watch and and or disagree.
when program starts
forever
if distance < 15 and is pressed? then
stop moving
if distance < 15 or is pressed? then
play beep 60 for 0.2 seconds
Nothing is within 15 cm and the bumper is out. Both conditions are false.
and was true in one row out of four. or was true in three. That is the whole difference, and it is why one of them makes a robot look broken.
The comparison is doing one job: it takes a reading that is neither true nor false and, by holding it against a number you chose, produces something a decision can use. The moment the blue fill crosses the black marker is the moment the answer changes.
Choosing the threshold
The number you compare against is a design decision, not a fact. “Close” for a parking sensor might be 15 cm; for a robot arm it might be 3. Pick it by measuring what the sensor actually reads in the situation you care about, then leave a margin.
Combining two conditions
and narrows: both must hold, so the robot acts less often but more certainly — stop only if something is close and the bumper is pressed. or widens: either will do, so the robot acts more readily — stop if something is close or the bumper is pressed.
In the four situations above, and was true in one of them and or in three. That is the practical difference: swapping one for the other does not adjust a robot slightly, it changes how often it reacts at all.
Say this back before moving on: “Armed, and really drawn. Otherwise, no.”
What’s in this build 4 min
Look at your robot. Four motors. Which two work as a pair, and which two work alone?
| Part | What it is doing here |
|---|---|
| EV3 Intelligent Brick | The body and the range officer. Its buttons arm and fire; its screen says which state the bow is in. |
| Large Motor ×2 — the drive | A matched pair. They move the robot to the shooting line. |
| Medium Motor — the draw | Pulls the string back and holds it. Its encoder is your safety evidence — the number of degrees it has turned is a direct measurement of how drawn the bow is. |
| Medium Motor — the release | Trips the catch. It is the irreversible step, and the only one with a guard on it. |
| The bow and its band (not electronic) | Stores the energy. Nothing in the program can put that energy back once the catch is tripped — which is what “irreversible” means. |
Find your own draw number, safely
- With no arrow loaded, set the draw mechanism to fully slack and run [A v] reset degrees counted.
- Draw it to its working position and read ([A v] degrees counted). Write the number down.
- Your interlock threshold goes a little below that — say 80% of it. Use your number, not the 300 in the example.
- Check the release trips cleanly from the drawn position, with no arrow, at least three times before you load anything.
Ports — and the rule 4 min
Sensors go in ports 1, 2, 3, 4. Motors go in ports A, B, C, D. They are not interchangeable, and nothing will tell you politely if you swap them.
| Part | Port | Why this one |
|---|---|---|
| Left drive wheel | B | The pair. Two motors, one job. |
| Right drive wheel | C | The other half of the pair. |
| Draw motor | A | Its own job — and the port whose encoder the interlock reads. Get this wrong and the guard is measuring the wrong motor. |
| Release motor | D | A separate job, at the far end of the port list from A, so a mis-typed port cannot make the draw motor fire. |
This is the first model in the course to use all four motor ports. The layout is not decoration: B/C is a pair, A and D are loners, and A and D are as far apart as the alphabet allows because confusing them is the one mistake that matters here.
The manual never says which port anything goes in — it ends at the last building step with no cables drawn. So the ports above are this course’s conventions, not the manual’s instructions, and nothing in your build contradicts them.
Check your own wiring now:
- Wheels in B and C, draw in A, release in D.
- Point the robot at the box before you plug anything in, and keep it that way.
- Route all four cables clear of the string’s path. A cable in the way of a drawn string is a jam under load.
- Leave the bow undrawn before every run. The program assumes it, and step 5 measured from there.
Connect the Brick 4 min
Two routes, and either is fine. USB is the reliable one and the one to fall back on when a room’s Bluetooth is busy; Bluetooth leaves the robot free to move, which some models need.
How to connect the BrickUSB and Bluetooth, step by step, with a photograph of every screen. Open it if you have not done this before — or if pairing is not working.Show meHide
USB — the reliable one
- Switch the Brick on with the dark grey centre button.
- Cable into the Brick’s PC port — the small square socket beside the numbered ports, not one of the numbered ones.
- Other end into the computer.
Bluetooth — name it first
Do these in order. Naming the Brick after you go looking for it in the list is how groups end up driving each other’s robots.
- Name your Brick. On the Brick: Settings (the spanner) → Brick Name. Type something nobody else will pick, then press the tick. Every Brick is called
EV3until somebody changes it. - Turn Bluetooth on. Settings → Bluetooth. Tick Bluetooth and Visibility. Leave iPhone/iPad/iPod unticked.
- Connect from EV3 Classroom. Click the Brick icon at the top of the programming area, find your Brick by name, and click Connect.
- Say yes on the Brick. It asks “Connect?” with the computer’s name — choose the tick, then accept the passkey, which is already 1234.
EV3.The two failures, every class, every time. The Brick has gone to sleep while you were building — press the centre button to wake it. Or you have paired with the group at the next table, which is why the name matters.
The long version, including Port View and how to read the port tiles, is in the Brick & Bluetooth guide.
Bluetooth, and stay in reach of the stop button. This robot drives and stores energy, so you want to be able to walk with it and still stop it. A cable puts you at the laptop instead of beside the machine.
Confirm the connection 2 min
- Check the Brick icon: connected, or not.
- Four motor tiles — A, B, C and D. Four is the number, and this is the first lesson where it is.
- Move the draw mechanism by hand and confirm tile A counts. Then move the release and confirm D. If those two are swapped, your interlock will guard the wrong motor and the release will fire unguarded.
- Do your draw measurement here, from step 5. Reset A at slack, draw by hand, read the tile. No program needed, and no energy stored longer than necessary.
Stuck? The long version, with a photograph of every screen, is in the Brick & Bluetooth guide.
Make it move 10 min
Four stacks: set up, drive to the line, arm, and a guarded release.
when program starts :: events hat set movement motors to [B v] and [C v] :: movement set [sedia v] to (0) [A v] reset degrees counted :: motors clear display :: display write [TIDAK SEDIA] at line (1) :: display when [up v] button [pressed v] :: events hat move [forward v] for (1) [rotations v] at (30) % speed :: movement when [left v] button [pressed v] :: events hat [A v] run [clockwise v] for (1) [rotations v] at (30) % speed :: motors set [sedia v] to (1) write [SEDIA ] at line (1) :: display when [center v] button [pressed v] :: events hat if <<(sedia) = (1)> and <([A v] degrees counted) > (300)>> then [D v] run [clockwise v] for (0.5) [rotations v] at (100) % speed :: motors set [sedia v] to (0) [A v] reset degrees counted :: motors write [TIDAK SEDIA] at line (1) :: display else play beep (45) for (0.5) seconds :: sound write [DITOLAK] at line (3) :: display end
- The guard is on the release and nowhere else. Driving and arming need no permission, because both can be undone.
- The
thenbranch does three things: fire, clear the flag, and reset the encoder. All three are part of “the shot is over”, and leaving any out leaves the machine lying about its own state. - The
elsebranch is not empty. A beep you can hear across the room and a message on the screen. A silent refusal is a fault report nobody receives. - Trailing spaces on
SEDIAso it fully coversTIDAK SEDIAunderneath. The display overwrites only the characters it is given.
What success looks like: press centre first, before arming. Nothing fires, the Brick beeps low, the screen says DITOLAK. Now press left — the bow draws, the screen says SEDIA. Press centre — it shoots, and the screen goes back to TIDAK SEDIA. Press centre again: refused.
If it refuses a properly drawn bow, your 300 is higher than your real draw — go back to your measurement. If it fires when it should not, stop and check that the draw motor really is on port A, because the guard is reading whichever motor is there.
Change it and test 8 min
One change at a time, and do all of these with no arrow loaded until the last one. The mechanism cycles perfectly well empty, and you are testing refusals, not range.
- Try to break it. Arm it, then un-draw the bow by hand, then press centre. Does it refuse? It should — the variable still says 1, and the encoder has told the truth.
- Now delete the encoder half, leaving only
(sedia) = (1). Do the same thing. It fires an undrawn bow, because the program’s belief was never checked against anything. - Delete the variable half instead, leaving only the encoder. Arm it and fire twice quickly. Does the second shot get through before the reset?
- Put both back and remove
set [sedia] to (0)from the then branch. Fire twice. The second one goes off on a bow that is no longer drawn — the machine forgot it had already fired. - Take out the
elsebranch entirely. Press centre unarmed: nothing at all. Ask somebody who has not seen the program to use it and watch how long before they say it is broken. - Add a third condition. Guard the drive stack too: refuse to move while
(sedia) = (1). A machine should not drive about with a loaded bow, and this is oneif.
Steps 2 and 3 together are the argument for using both. The variable knows things the encoder cannot — like whether a shot has already been taken. The encoder knows things the variable cannot — like whether a human interfered. Neither alone is a safety check. Together they are hard to fool.
An interlock is not one check. It is every check the dangerous step depends on, joined by and.
