EV3 Robotics›Level 3 · Advanced›Lesson 40
Level 3 · Lesson 40 · EV3-L03-4060 minutes · Ages 9–16 · Model: EV3 IP MAN 1
IP Man: a training dummy whose arm swings on a motor, and a second, faster motor whose job is to block that arm at exactly the right instant.
Every model so far has reacted to where something is. Try that here and you will always miss — by the time the sensor reports the arm arriving, the block has not even started moving.
By the end of the lesson your machine will fire early, by an amount you have measured rather than guessed — and it will still work when you change the arm’s speed.
The wooden dummy — mook jong — is how Wing Chun students drill against a fixed opponent. What they are training is not strength. It is starting the block before the strike arrives, because a human arm needs about a fifth of a second to get anywhere and a strike does not wait.
Every fast sport is the same. A cricketer plays the ball from where it will be. A table-tennis player has committed to a shot before the ball crosses the net. A goalkeeper facing a penalty starts to move before the striker’s foot lands.
Because nothing reacts instantly, and the delay is not a fault to be fixed — it is a known quantity to be planned around. Nerves take time. Motors take time to spin up. A camera takes time to produce a frame.
An engineer measures that delay once and then builds it into the plan. A camera on a bottling line triggers the reject arm for a bottle that has not reached it yet, using the belt speed and the known distance. Nobody tunes that by eye.
You get a machine that is always a fraction late and cannot be fixed by trying harder. Speeding up the loop shaves milliseconds off a delay measured in tenths of a second — the arrow is pointing at the wrong problem.
If you cannot be instant, be early — by exactly as much as you are slow.
Between deciding and doing there is a gap. Call it the lag. To arrive on time, act one lag early — and the only honest way to know the lag is to measure it.
| Quantity | What it is | How you get it |
|---|---|---|
| Lag | Command sent → block actually in place. | Measure it: reset the timer, fire the block, wait until it arrives, read the timer. Twenty times, and average. |
| Period | How long the arm takes to come round once. | Measure it: time between two presses of the Touch Sensor. |
| Lead | How early to fire. | Compute it. Fire when the arm is lag away from the block, not when it is at the block. |
The arm passes a reference point, then reaches the block a fixed time later. So after the reference press you wait — but for less than the full travel time.
// travel = how long from the reference point to the block // lag = how long the block takes to get there // so wait the difference, then fire set [wait for v] to ((travel) - (lag)) :: variables if <(wait for) < (0)> then set [wait for v] to (0) :: variables end wait until <[1 v] is pressed? :: sensors> wait (wait for) seconds :: control [A v] run to position (90) [degrees v] at (100) % speed :: motors
If the lag is longer than the travel time, no amount of cleverness will get the block there. The machine is physically too slow, and the honest fix is a faster block or an earlier reference point — not a bigger number. Watching a program hit that wall is worth more than a working one.
Lesson 5’s closed loop watches an error and corrects it. That works beautifully when there is time to notice being wrong. Here there is not. By the time the error exists, the strike has landed.
So you use the other half of control: feed-forward — act from what you know about the system rather than from what has already gone wrong. Fast machines use both, and Lesson 48 will finally put them together.
A wait pauses for a length of time. The timer is different: it runs in the background and can be read at any moment, so the robot can know how long something has taken while it is still happening.
| Block | What it does |
|---|---|
(timer) | Reports the seconds since the timer was last reset. |
reset timer | Sets it back to zero, so the next reading counts from here. |
The most valuable use of a timer is escaping a wait that might never end. A robot told to drive until it sees a wall will drive for ever if the wall is not there. Combined with a timer, it can give up:
Repeat until the wall is close or five seconds have passed. That one change turns a program that can hang into one that always finishes. Both robots below are looking for a wall that is not there.
no way out
with a timeout
The sensor is not faulty and the program is not wrong. There is simply no wall, and only one of these two programs has a way of noticing that.
The left-hand robot is not broken, and neither is its sensor. Its condition is simply one that will never come true, so the program sits on that block for ever — with nothing on the Brick to say so. The right-hand program asks the same question with an escape route bolted on, and finishes every time.
Real systems time themselves out constantly — a lift that cannot close its doors eventually gives up and beeps rather than trying for ever. A robot with no timeout simply stops responding, and there is nothing on screen to say why.
The Touch Sensor is the simplest input the EV3 has: a button that is either pressed or not. That sounds trivial, but it is how a robot knows it has hit a wall, reached the end of a track, or been told to start by a person.
released
pressed| Block | What it does |
|---|---|
wait until <[1 v] is pressed? :: sensors> | Holds the program here until somebody presses the sensor. |
<[1 v] is pressed? :: sensors> | Reports true or false. Drop it into a condition to make a decision rather than a wait. |
[1 v] when [bumped v] :: events hat | Starts a whole stack of its own. The dropdown chooses the moment: pressed, released or bumped. |
A button is not only “pressed”. One press is three things: the moment it goes down, the time it stays down, and the moment it comes back up. Watch what a single press does to three programs at once.
versus two hat blocks
The middle counter is the one that surprises people. Nothing is wrong with it — a loop really does check that fast, and every check really is a separate answer.
Nothing there is broken. A loop really does get round hundreds of times a second, and each time it asks is pressed? the honest answer is still yes — so if that loop plays a sound or counts something, it does it hundreds of times from one finger. The two hat blocks each fire once, and they fire at different moments: pressed the instant the button goes down, bumped only when it comes back up.
The three options, and what each is for:
when program starts :: events hat set movement motors to [B v] and [C v] :: movement start moving [straight: 0] :: movement wait until <[1 v] is pressed? :: sensors> stop moving :: movement
The robot drives until something presses the sensor. Note that the movement is started unmeasured on purpose — the sensor decides when to stop, not a distance.
Touch sensors are everywhere in machines you cannot see into: a lift knows the doors are shut, a printer knows the lid is closed, a washing machine will not spin until it is latched. They are safety devices as much as inputs.
Long before there were computers, people had exactly this problem. A shepherd counting sheep through a gate, a trader counting sacks of grain, a builder counting days — none of them can hold the number in their head while they get on with the work. So they scratched a mark on a wall, cut a notch in a stick, or wrote a number on a piece of paper. The number lived outside the person, in a place they had agreed on, and they could go back to it, read it, and change it.
Better still, once the number is written down somebody else can use it. Watch these two: one of them counts and writes, the other never sees a single animal and simply reads the wall.
Notice what never happens: Ben never asks Abby. He does not need to — the number is not in her head, it is on the wall, and the wall is there for anyone who needs it.
Neither Abby nor Ben is holding the number — the wall is. And notice what never happens: Ben does not ask Abby. He does not need to, because the count is not in her head. It is in a place they both agreed on, which is what makes it useful to more than one of them.
That is all a variable is. The robot cannot hold a number in its head either, so you give it a wall of its own, write a name at the top so everyone knows which wall is which — score, count, degree_turn — and the program can read what is on it and write something new. One part of the program writes; another part reads. Exactly Abby and Ben.
Say we are counting rotations of a motor. Before we start we write 0 on the paper. Every time the motor completes a turn we cross out what is there and write one more: 0 becomes 1, then 2, then 3. That is change — it has to read the old number to work out the new one.
set is the other thing you can do, and it is completely different: rub the whole paper out and write the number you want. It does not care what was there. Press the buttons and watch what happens to the crossings-out.
The paper starts blank, so we write 0 on it. That is what a variable is: a place to keep a number while the robot works.
| Block | What it does |
|---|---|
set [count v] to (0) | Puts a value in, replacing whatever was there. |
change [count v] by (1) | Adds to what is already there. |
(count) | Reports the current value, for use in a comparison or on the display. |
set replaces; change adds. Counting things needs change. Starting a count needs set. Both programs below have both blocks — the only difference is whether the set block is inside the loop or above it.
set before the loop
set inside it
Both programs contain both blocks. Only the position of set [count] to 0 is different.
The count on the right is not broken; it is being told to start again on every pass. Each time round the loop it is wiped back to zero and then changed by one, so the honest answer is always 1 — while the motor cheerfully turns four times. A counter stuck at 1 almost always means a set block that has slipped inside the loop.
EV3 Classroom tells you what a block does by its shape, and once you have noticed that, a whole set of questions answers itself:
So when a slot is oval, any oval fits it — and it does not matter in the least where that number came from. You can take the motor’s own A degrees counted and keep it in a variable you named degree_turn, then compare that with a number later. Pick an oval below and watch the same one drop into all three kinds of slot.
pick an oval
the same oval fits all three
Every one of those slots is oval-shaped, and A degrees counted is an oval — so it drops in. Nothing about where the number came from matters.
This is what makes a variable more than a counter. A sensor reading is true only at the instant you read it; copying it into a variable freezes it, so the robot can compare where it is now against where it was when something happened:
when program starts :: events hat [A v] reset degrees counted :: motors set [degree_turn v] to ([A v] degrees counted :: sensors) start moving [right: 30] :: movement wait until <(([A v] degrees counted :: sensors) - (degree_turn)) > (400)> stop moving :: movement
Read the condition aloud: how far the motor has gone now, minus where it was when we started, is more than 400. Both are ovals, so both can go into a subtraction, and the subtraction is an oval too — which is why it can go into a comparison. Ovals nest inside ovals as deep as you need.
A variable keeps its value after the program ends. Run the program again without setting it back and the second run begins where the first left off — the count starts at 14, the robot thinks it has already done the job. Every variable a program changes must be set to its starting value at the top.
A variable is the difference between a machine that repeats a fixed routine and one that responds to how things have gone — counting parts, tracking a score, remembering where it started.
Measure the lag. Subtract it. Do not tune it by feel.
Long before there were computers, people had exactly this problem. A shepherd counting sheep through a gate, a trader counting sacks of grain, a builder counting days — none of them can hold the number in their head while they get on with the work. So they scratched a mark on a wall, cut a notch in a stick, or wrote a number on a piece of paper. The number lived outside the person, in a place they had agreed on, and they could go back to it, read it, and change it.
Better still, once the number is written down somebody else can use it. Watch these two: one of them counts and writes, the other never sees a single animal and simply reads the wall.
Notice what never happens: Ben never asks Abby. He does not need to — the number is not in her head, it is on the wall, and the wall is there for anyone who needs it.
Neither Abby nor Ben is holding the number — the wall is. And notice what never happens: Ben does not ask Abby. He does not need to, because the count is not in her head. It is in a place they both agreed on, which is what makes it useful to more than one of them.
That is all a variable is. The robot cannot hold a number in its head either, so you give it a wall of its own, write a name at the top so everyone knows which wall is which — score, count, degree_turn — and the program can read what is on it and write something new. One part of the program writes; another part reads. Exactly Abby and Ben.
Say we are counting rotations of a motor. Before we start we write 0 on the paper. Every time the motor completes a turn we cross out what is there and write one more: 0 becomes 1, then 2, then 3. That is change — it has to read the old number to work out the new one.
set is the other thing you can do, and it is completely different: rub the whole paper out and write the number you want. It does not care what was there. Press the buttons and watch what happens to the crossings-out.
The paper starts blank, so we write 0 on it. That is what a variable is: a place to keep a number while the robot works.
| Block | What it does |
|---|---|
set [count v] to (0) | Puts a value in, replacing whatever was there. |
change [count v] by (1) | Adds to what is already there. |
(count) | Reports the current value, for use in a comparison or on the display. |
set replaces; change adds. Counting things needs change. Starting a count needs set. Both programs below have both blocks — the only difference is whether the set block is inside the loop or above it.
set before the loop
set inside it
Both programs contain both blocks. Only the position of set [count] to 0 is different.
The count on the right is not broken; it is being told to start again on every pass. Each time round the loop it is wiped back to zero and then changed by one, so the honest answer is always 1 — while the motor cheerfully turns four times. A counter stuck at 1 almost always means a set block that has slipped inside the loop.
EV3 Classroom tells you what a block does by its shape, and once you have noticed that, a whole set of questions answers itself:
So when a slot is oval, any oval fits it — and it does not matter in the least where that number came from. You can take the motor’s own A degrees counted and keep it in a variable you named degree_turn, then compare that with a number later. Pick an oval below and watch the same one drop into all three kinds of slot.
pick an oval
the same oval fits all three
Every one of those slots is oval-shaped, and A degrees counted is an oval — so it drops in. Nothing about where the number came from matters.
This is what makes a variable more than a counter. A sensor reading is true only at the instant you read it; copying it into a variable freezes it, so the robot can compare where it is now against where it was when something happened:
when program starts :: events hat [A v] reset degrees counted :: motors set [degree_turn v] to ([A v] degrees counted :: sensors) start moving [right: 30] :: movement wait until <(([A v] degrees counted :: sensors) - (degree_turn)) > (400)> stop moving :: movement
Read the condition aloud: how far the motor has gone now, minus where it was when we started, is more than 400. Both are ovals, so both can go into a subtraction, and the subtraction is an oval too — which is why it can go into a comparison. Ovals nest inside ovals as deep as you need.
A variable keeps its value after the program ends. Run the program again without setting it back and the second run begins where the first left off — the count starts at 14, the robot thinks it has already done the job. Every variable a program changes must be set to its starting value at the top.
A variable is the difference between a machine that repeats a fixed routine and one that responds to how things have gone — counting parts, tracking a score, remembering where it started.
Say this back before moving on: “How slow am I, and how early does that make me fire?”
Fire the block by hand from the Brick and watch it. Does it snap across, or does it ease into place? Everything that eases is lag, and lag is the number this lesson is about.
| Part | What it is doing here |
|---|---|
| EV3 Intelligent Brick | The trainer. Its screen carries the two measured numbers, which is what turns the lesson from tuning into engineering. |
| Large Motor — the swinging arm | The target. Its speed sets the whole timetable, so changing that speed must change the lead — otherwise the machine has only memorised one situation. |
| Medium Motor — the block | Must be the fast one. Its lag is what you are compensating for, and a Large motor here would make the lag longer than the travel time. |
| Touch Sensor — the reference point | Pressed by the arm at a known place in its swing. It does not say “block now” — it says “the clock starts now”. |
| Colour Sensor — the hit | Reports whether the block was actually in the way. Without it you are judging your own timing by eye at a tenth of a second, which nobody can do. |
The reference point must be far enough before the block to leave room for the lag. If the Touch Sensor sits right beside the block, the machine has no warning at all and the lesson has nowhere to go. Move it back along the swing.
Sensors go in ports 1, 2, 3, 4. Motors go in ports A, B, C, D. They are not interchangeable, and nothing will tell you politely if you swap them.
| Part | Port | Why this one |
|---|---|---|
| Block (Medium) | A | The fast, precise motor. |
| Arm (Large) | B | The strong one — it swings a long lever. |
| Reference (Touch) | 1 | Touch stays on 1 across the course. |
| Hit (Colour) | 3 | Colour stays on 3 across the course. |
Check your own build now:
Two routes, and either is fine. USB is the reliable one and the one to fall back on when a room’s Bluetooth is busy; Bluetooth leaves the robot free to move, which some models need.
Do these in order. Naming the Brick after you go looking for it in the list is how groups end up driving each other’s robots.
EV3 until somebody changes it.EV3.The two failures, every class, every time. The Brick has gone to sleep while you were building — press the centre button to wake it. Or you have paired with the group at the next table, which is why the name matters.
The long version, including Port View and how to read the port tiles, is in the Brick & Bluetooth guide.
Use Bluetooth, and check the battery before measuring. A tired battery makes both motors slower, which changes the lag and the travel time together — measure on a fresh battery or your numbers will drift under you.
Stuck? The long version, with a photograph of every screen, is in the Brick & Bluetooth guide.
Three programs: one that fails on purpose, one that measures, and one that uses the measurements.
when program starts :: events hat [B v] start motor [clockwise v] at (40) % speed :: motors forever wait until <[1 v] is pressed? :: sensors> [A v] run to position (90) [degrees v] at (100) % speed :: motors [A v] run to position (0) [degrees v] at (100) % speed :: motors end
when program starts :: events hat clear display :: display // ---- how long does the block take to arrive? ---- set [total v] to (0) :: variables repeat (10) [A v] run to position (0) [degrees v] at (100) % speed :: motors wait (0.5) seconds :: control reset timer :: control [A v] run to position (90) [degrees v] at (100) % speed :: motors set [total v] to ((total) + (timer)) :: variables end set [lag v] to ((total) / (10)) :: variables write (lag) at line (1) :: display // ---- how long from the reference point to the block? ---- [A v] run to position (90) [degrees v] at (100) % speed :: motors [B v] start motor [clockwise v] at (40) % speed :: motors set [total v] to (0) :: variables repeat (5) wait until <[1 v] is pressed? :: sensors> reset timer :: control wait until <([3 v] reflected light intensity) < (25)> set [total v] to ((total) + (timer)) :: variables wait until <not <[1 v] is pressed? :: sensors>> end set [travel v] to ((total) / (5)) :: variables [B v] stop motor :: motors write (travel) at line (3) :: display
when program starts :: events hat
set [lag v] to (0.35) :: variables // your measured numbers
set [travel v] to (0.60) :: variables
set [blocked v] to (0) :: variables
set [missed v] to (0) :: variables
[A v] run to position (0) [degrees v] at (100) % speed :: motors
set [lead v] to ((travel) - (lag)) :: variables
if <(lead) < (0)> then
set [lead v] to (0) :: variables
write [TOO SLOW TO BLOCK] at line (7) :: display
end
[B v] start motor [clockwise v] at (40) % speed :: motors
forever
wait until <[1 v] is pressed? :: sensors>
wait (lead) seconds :: control
[A v] run to position (90) [degrees v] at (100) % speed :: motors
reset timer :: control
set [hit v] to (0) :: variables
repeat until <<(hit) = (1)> or <(timer) > (0.5)>>
if <([3 v] reflected light intensity) < (25)> then
set [hit v] to (1) :: variables
end
end
if <(hit) = (1)> then
change [blocked v] by (1) :: variables
play sound [Mechanical / Blip 4 v] :: sound
else
change [missed v] by (1) :: variables
end
[A v] run to position (0) [degrees v] at (100) % speed :: motors
write (blocked) at line (3) :: display
write (missed) at line (5) :: display
wait until <not <[1 v] is pressed? :: sensors>>
endlead is computed, not typed. Change either measurement and the timing follows automatically.What success looks like: the block is already in place as the arm arrives, and after twenty swings the blocked count is far ahead of the missed one.
If it is still late, re-measure the lag — a motor that has to reverse first is slower than one starting from rest. If it is now early, the block gets there and retracts before the arm arrives; hold the position for a moment before returning.
One change at a time. Predict, then run, then look. Predict using the numbers, not by feel — that is the skill.
A machine that measures its own lag keeps working when the world changes. One with a tuned number does not.
IP Man deals in one dimension: how long until the arm is here. The next model has to say where, on a flat sheet of paper.
The Pen Arm swings and reaches. It cannot move left and right — it can only choose an angle and a distance along the arm, and every point on the page has to be expressed in those two.
That is the same pair of numbers a record player’s tonearm, a radar dish and a crane all work in — and converting between them and ordinary x and y is what makes a drawing come out straight.
Today the machine aimed in time. Next it aims in space, without using x and y.
Build the model before you read any further. Everything after this is about making it do something, and none of it will make much sense with nothing on the table in front of you.
Use the viewer's own controls to zoom and turn pages. Fullscreen makes it big enough to build from.
The same build on Google Drive — sometimes a video, sometimes a scan:
Use the viewer's own controls to zoom and turn pages. Fullscreen makes it big enough to build from.
Check the finished build against the picture before you switch anything on. A motor mounted the wrong way round is far easier to spot now than it is to debug later, when it looks like a program fault.
Work through the challenges in order — each is harder than the last. The mission comes after all three, and it is meant to make you plan before you build.
Measure the lag twenty times. Reset the timer, fire the block, wait until it arrives, read the timer. Twenty runs. Report the average and the spread. If the spread is large, say what is causing it — a motor starting from rest is not the same as one reversing.
Change the arm speed and predict the miss count first. Drop the arm to 70 percent without touching the lead. Write your prediction down BEFORE running it, then run twenty swings and compare. Then re-measure travel at the new speed, put it in, and report the new counts. Predicting from numbers is the skill; the working machine is just the receipt.
Push it past what it can do. Slow the block motor until the computed lead goes negative and the machine says it cannot block in time. Report the block speed at which that happens. Then say which two things you could change to fix it, and why a bigger lead number is not one of them.
Make it adapt on its own. Program the machine to measure both numbers at start-up — timing two swings for travel and two block movements for lag — and then block for a hundred swings. Requirements: 1. Nothing typed in. Every number in the timing comes from a measurement the machine took. 2. The lead computed, never tuned. 3. A negative lead reported honestly on screen instead of silently clamped and forgotten. 4. Blocked and missed counted separately and shown. 5. It still works after somebody changes the arm speed and restarts it, without you touching the program. Then have somebody change the arm speed to a value you were not told, restart it, and run twenty swings. Report the score. A machine that measures its own lag survives a world it was not tuned for; one carrying a number you found by trial and error does not, and the difference only shows up when somebody changes something behind your back.
